该软件系统具有自己的CAD编辑功能，可以方便快捷地选择和修改图形。
进料采用三点单线设计，实现进退刀的平稳运行。
刀片让路式防堵塞刀设计，当刀片因某种原因堵塞时，进料会自动停止。
当双工位组合模具严重磨损且无法冲孔时，推进电机将自动反转并返回等待并提示终止加工。
自动识别唇削和驳船自动加长，整机采用三头设计，实现单套拉削和单套刻痕。
刻痕可以根据标记线的长度自动识别点宽度，自动识别大小和角度，并自动打开大角度拉削。
|
Broaching hickness |
0.45mm-0.71mm |
|
Broaching height |
8mm-32mm |
|
Nicking height |
8mm-32mm |
|
Nicking hickness |
0.53mm-1.05mm |
|
Support grinding head and ail bevel range |
The software can set he starting angle to grind he beveled edge arbitrarily |
| Maximum unslotted bending Angle: | 100° |
| Minimum bending size of head and tail: | 1.5-2mm depending on the blade thickness |
| U-shaped minimum bending spacing: | Spacing 5mm(5mm above dimensions Software automatically avoid releasing back corner bending) |
| Minimum shear size of head and tail: | 1mm |
| Cutting mode: | One - time two-way automatic judgment shear, when the insufficient shear level automatic two - time multi - feed pull back shear |
| One-time shear blade range: |
Height：8mm-32mm（Exceed bending break） thickness：0.53mm-1.05mm |
| Feeding accuracy: | ±0.05mm |
| Flatness of bending: | ±0.5mm |
| Support bending blade height: | 8mm -35mm(more than option) |
| Support bending blade height: | 0.45mm -1.05 mm |
| Minimum bending arc: | Blade thickness +1mm or more |
| Bridge width size: |
Width optional: 3mm to 6mm Bridge height manual adjustment rod adjustment Software according to the bridge width support automatic wide Olecranon size manual adjustment lever adjustment |
| Best graphics format: | dxf.ai.dwg |
| Equipment environment: | Ventilated, dry below 40 degrees |
| Equipment pressure requirements: | 4Kg/cm2 pressure, 10mm throat diameter |
| Power supply requirements: | AC:220V 50Hz must be properly grounded |
| Machine power: | 2.0kw |
| Weight of whole machine including wooden case: | 500KG |
| Equipment outline, cover area and wooden box size: |
230cm×75cm×165cm(footprint) 165cmX135cmX80cm(Equipment wooden case size) |
| Machete machine system support language: | Simplified Chinese and English |
| Software Computer operating platform: | Windows7 or later |
The whole machine has 7 sets of servo drives and adopts Ethernet transmission control, which is fast and stable.
The feeding adopts double clamping cutters, front and back teeth Taiwan TBI front and rear screw rods, equipped with upper and lower upper and lower silver guide rails.
The whole machine is driven by high-precision servo drives imported from Japan, and equipped with Japanese Xinbao high-precision reducers, which are efficient and stable.
The pneumatic part adopts Japanese SMC cylinder, Taiwan original AirTAC solenoid valve, and Taiwan series sensor.
Combined power adopts lapping turbine motor and energy-saving motor respectively, with low noise and power saving.
